Description
| Rated Power: | 58kW@2400rpm | ||
| Operating Weight: | 6645kg | ||
| Rated Load: | 2500kg | ||
Main Specifications: |
|||
| Engine: | YC4D80-T20 | ||
| Rated Power: | 58kW | ||
| Transmission: | Fixed Shaft, Power Shift | ||
| Gears: | 2 Forward, 2 Reverse | ||
| Differential: | Spiral bevel gear, First reduction | ||
| Total Cycle Time: | > 9s | ||
| Service Brakes: | Air-Over-Oil Calliper Discs | ||
| Hydraulic System: | Oil Pump type Gear | ||
| Control Type: | Pilot Control | ||
| System Pressure: | 17.5 MPa | ||
| Loader & Bucket: |
|
||
| Rated Load: | 2500 kg | ||
| Breakout Force, Std Bucket: | 58 kN | ||
| Gradeability: | 30⁰ | ||
| Max. Traction Weight: | 56 kN | ||
| Min. Ground Clearance: | 293mm | ||
| Dump height @ 44º: | 2718mm | ||
| Dump Distance @ 44º: | 946mm | ||
| Dimensions: |
|
||
| Overall Width: | 2150mm | ||
| Height Top of Cab: | 3019mm | ||
| Operating Weight: | 6200kg | ||
| Tyres: | 16/70-20-14PR | ||
| Wheel Base: | 2260mm | ||
| Wheel Tread: | 1630mm | ||
| Standard equipment: | ENSIGN axles & transmission | ||
| ROPS/FOPS cab | |||
| General bucket | |||
| Pilot control | |||
| Air conditioner | |||
| Back-up alarm | |||
